What is SOLIDWORKS MBD?
SOLIDWORKS® MBD (Model Based Definition) is an integrated drawingless manufacturing solution for SOLIDWORKS 3D design software.
You can communicate product and manufacturing information (PMI) directly in 3D, bypassing time-consuming 2D processes, and eliminating potential problems.
Why drawingless communication works?
SOLIDWORKS MBD defines PMI directly in 3D and avoiding the expensive, time-consuming, and risky 2D drawing detour. 3D PMI helps speed up communication, cut quoting time, and reduce errors thanks to its 3D data interrogation, interactivity, and rich Meta properties.
Companies embracing model-based definition methodologies report savings in multiple areas, including reductions in manufacturing errors, decrease in scrap and rework costs, and lower procurement costs for purchased parts.
Overview Demo
Take a first look at SOLIDWORKS MBD
SOLIDWORKS MBD Capabilities
Capture complete product data, including title block and BOM information, in multiple 3D Views that can be easily exported to industry standard formats.
“Because SOLIDWORKS is a full-featured, integrated product development environment, it helps us design very quickly and competitively. It has an extensive range of technologies and tight integration between all of the modules that we use across the entire order lead-time.”
Virgilio Sisti
R&D–Mechanical Designer/CAD Manager, Baltur
“The instruments we build are used all over the world to protect human life. We are making a difference.”
Tricia Harrison
Manager of Product Development, Measurand
SOLIDWORKS MBD Features
Share 3D PMI data to get designs to production faster
Present 3D data in a clean and structured fashion
Beyond 3D PMI definition, SOLIDWORKS MBD helps organize the rich data into clean and structured 3D presentations with different views and display settings.
It can even intelligently show and hide 3D annotations while you are rotating the model to give you extra clarity while still respecting all the critical-to-function annotations.
SOLIDWORKS MBD sets data such as product models, dimensions, geometric tolerances, surface finishes, welding symbols, bill of materials (BOM), callouts, tables, notes, Meta properties, and other annotations.
Customize 3D output templates
SOLIDWORKS MBD delivers a comprehensive set of predefined templates out-of-the-box.
Several aspects of the 3D Output Template, such as layout, company, or department logos; 3D viewport and thumbnails; text descriptions; Meta-property links; and tables can also be customized to address specific deliverables, such as Engineering Drawings, Request for Quote (RFQ), and Inspection Reports.
Once set up, these templates can serve as internal and external process guidelines for all departments, such as manufacturing, operations, quality, and procurement.
Output and distribute 3D data to an existing process
SOLIDWORKS MBD publishes widely accepted file formats, such as eDrawings® and 3D PDF files that are often used in existing processes. eDrawings files can be opened in a free eDrawings Viewer.
3D PDF can be viewed using a variety of free tools including Adobe™ Reader. In addition to providing associative information such as engineering notes, BOM, and rich Meta properties, you can also explore the model in 3D with Pan, Zoom, Rotate, Measure, Section, and other 3D tools.
Looking for a Cloud Alternative?
3DEXPERIENCE Works provides a Safe, Social, Connected, Informed and Structured alternative to SOLIDWORKS MBD for team leaders, project managers and other professionals who want to manage data on the cloud and collaborate without constraints.
Safe: Customer controlled access. Transparent cloud backup. Encrypted communication protocols. Data always safe-no overwrite, no loss of data.
Social: Integrated structured and unstructured collaboration tools enabling social innovation. Collaborate on product design or engage with your stakeholders early in product development.
Connected: Every user always connected to a single, common database. Access data anywhere, anytime, on any device. Review and markup models.
Informed: Choose from the widget library, Create and share Dashboards. Get the latest information about your product development. Always have access to your latest data.
Structured: Zero overhead data management - store and manage data across collaborative spaces, share information in communities. Find indexed data faster by using tags, custom search, etc.
